Wiring Harness for Gibson SG Jimmy Page

Regular price $115.00

NOTE: Very Important! The SG body is traditionally very thin. You must measure the interior depth of your SG control compartment to see if these pots will fit. The Bourns push/pull pots need 1-1/8 inch clearance to fit, or 1-1/16 inch if the star washer is removed.  The only other option is to have the floor of the control cavity routed down slightly at a professional guitar repair shop.


With the success of our Les Paul Jimmy Page system, we now offer our new wiring harness Jimmy Page upgrade for Gibson SG!


This system includes everything you need to transform a Gibson SG into the famous "Jimmy Page" wiring. 4-conductor humbucker pickups are required. The Bourns Push/Pull pots allow you to split your humbuckers into single coil pickups, allows both pickups to be put out of phase, and can put both pickups in series as well. AND...with the 3 way switch in the bridge position, the neck tone pot will act as a kill switch when pulled up!

Included in each SGJP system:

4) Bourns 500K Push/Pull Audio Taper volume & tone pots, 3/8" Long Threaded Bushing, Split Shaft, DPDT
2) "Orange Drop" .022 mfd 100 volt Capacitors
1) Wiring diagram (see photo section)
1) Assembly template board

Note: this is a very complex wiring system and needs to be installed by a qualified guitar repair technician

Wiring diagram (sent via email)

Replace your old worn out parts with these premium replacement units! Each set is assembled, hand wired and soldered in the USA using premium parts. Each unit signed by Dave Starr and have their own serial number.
